Pro Convert AIO RX 影音網路 NDI 連結轉換器
Magewell 相關連結 : Pro Convert | Ultra Stream | USB Capture | USB Capture Plus | ECO Capture | Pro Capture | 應用程式
Pro Convert AIO RX 影音網路 NDI 連結轉換器 即將發售
Pro Convert AIO RX 影音網路 NDI 連結轉換器， 獨立標準 NDI 解碼器
重點功能
● 將 NDI 視訊轉成 HD HDMI/3G-SDI信號
美樂威 Magewell Pro Convert 系列
Magewell Pro Convert HDMI 4K PLUS 網路 NDI 連結轉換器
Magewell Pro Convert HDMI PLUS 網路 NDI 連結轉換器
Magewell Pro Convert HDMI TX 網路 NDI 連結轉換器
Magewell Pro Convert SDI 4K PLUS 網路 NDI 連結轉換器
Magewell Pro Convert SDI PLUS 網路 NDI 連結轉換器
Magewell Pro Convert SDI TX 網路 NDI 連結轉換器
Magewell Pro Convert AIO 網路 NDI 連結轉換器
Magewell Pro Convert for NDI to HDMI 4K 網路 NDI 連結轉換器
Magewell Pro Convert for NDI to HDMI 網路 NDI 連結轉換器
詳細規格
| Model | Pro Convert AIO RX | ||
| Supported Web Browser (tested) |
Microsoft Internet Explorer 11 Microsoft Edge Mozilla Firefox version 61 and above Google Chrome version 49 and above Apple Safari 11.1 and above Opera 55.0.2994.44 and above |
||
| Output Interface | 3G-SDI / HDMI 1.4 | ||
| Storage Interface | SD Card (functions to be developed) | ||
| PTZ + TALLY Control | Mini-DIN–8 jack | ||
| Screw Mounting Hole | ¼–20 mounting hole | ||
| Network Interfaces |
10/100/1000Mbps Ethernet IEEE 802.3af PoE |
||
| USB Interface |
USB2.0 Type B 5V/2.1A power supply USB RNDIS/ECM |
||
| Set Buttons |
Preset - Long press：set the output video format to auto - Short press：rotate the preset output resolution list Source - Short press：rotate the NDI® source detected on the LAN |
||
| HDMI Output Features |
Support RGB 4:4:4, YUV 4:4:4, YUV 4:2:2 color sampling Support up to 48KHz 16bits 8-channel audio streams Support outputting video streams at the optimal resolution for NDI® source automatically Support the following output format - SD：480i59.94/576i50/480p59.94/576p50 - HD：720p24/25/29.97/30/50/59.94/60; 1080p24/25/29.97/30; 1080i50/59.94/60 - FHD：1080p50/59.94/60 |
||
| SDI Output Features |
Support SD/HD/FHD standards Support YUV 4:2:2 color sampling Support up to 48KHz 16bits 8-channel audio streams Support outputting video streams at the optimal resolution for NDI® source automatically Support the following output format - SD：480i59.94/576i50/480p59.94/576p50 - HD：720p24/25/29.97/30/50/59.94/60; 1080p24/25/29.97/30; 1080i50/59.94/60 - FHD：1080p50/59.94/60 |
||
| NDI Output Format |
Support for 4:2:2 8-bit output Support for up to 2048x2160 120fps Support for NDI 4.1 |
||
| NDI Source Name |
Support for setting the device name shown in the system using Web UI. By default, the device name is ‘Pro Convert’. Support for setting board-index, from 0 to F, through on-board rotary switch |
||
| Firmware Upgrade | Support for manual update using Web UI | ||
| LED Indicator |
Status LEDs indicate: - the state of power supply: on/off - Output signal: Output connected and signal detected/undetectem |
||
| Form Factor | 100.9mm (L) x 60.2mm (W) x 23.3mm (H) | ||
| Accessories |
USB 2.0 A to B Cable 5V/2.1A power adaptor L-bracket |
||
| Power Consumption | 5V max current: TBD / Max power consumption: TBD | ||
| Working Environment |
Operating temperature: 0 to 45 deg C Storage temperature: –20 to 70 deg C Relative Humidity: 5% to 90% non-condensing |
||
以上資料僅供參考，實際規格請以原廠產品公佈資訊為標準，如有更新，不另行通知
